The ID Mounted beveling operation utilizes an expandable mandrel which is slid into the open end of the pipe. Draw nut is tightened, which expands the mandrel blocks up a ramp and against the ID surface for positive mounting, self centered and squared to the bore. As the tool bit is fed in to the material from the end, bevel is produced which confirms to the angle predetermined by the angle ground in to the bit. Bits are available for practically any material or beveling required, and bits can be custom made for any form tooling operation.

Features

• Cold Beveling
• Fast, Precision On-site Beveling
• Minimal Axial and Radical clearance
• Light weight and compact design
• Easy set-up & robust operation
• Electric at Pneumatic drive

ID MOUNT END PREP BEVEL
