ANCHOR
POINTS
u
One Central Eye Bolt : Main Anchor
Point.
u
Three Lateral Eyes Additional Anchor
Points, Easy To Hang Other Safety Devices.
HAND
WINCH CONNECTING PART
u
Hand Winch : Fitted With Self-lock
Device, Equipped With 30m Wire Rope.
u
Connecting Part : Newly Designed And
Fastened By Two Lock Pins.
Features
u
The Tripod Is The Anchorage Connector
For Typical Confined Space And Rescue Systems.
u
It Feature A Light Weight, High-strength
Aluminium Construction.
u
I Central Eye Bolt And 3 Additional
Lateral Eyes, Easy To Hang Various Safety Devices.
u
Connecting Part Is Fitted With Safety
Lock Pin, To Keep Hand Winch From Slipping Up.
u
Telescoping Legs Caster To Different
Operating Heights.
u
Ring Type Safety Chain Is Supplied To
Minimize Horizontal Forces And Prevent The Legs Spreading And Collapsing.
u
Steel Feet Incorporate A Rubber Sole For
Flat Surfaces And Spiked Edges For Slippery Surfaces.
u
Equipped With Hand Winch C/w Self-lock
Device.
u
Comply With Council Directive 89/686/EEC
And Standard EN 795.
Technical Data For Tripod
u
Working Load Limit : 200kg.
u
Working Height :
- Legs Fully
Extended 214cm
- Legs Fully
Retracted 1.34cm
u
Anchor Points In The Head :
1 Main Central
Eye Bolt
3 Additional
Lateral Eyes
u
Main Parts : Made Of High Strength
Aluminium Alloy.
For Hand Winch :
u Rated
Capacity : 1800LBS
u Wire
Rope : Diameter :4mm, Length : 30m, Gear Ratio - 8:1
